Double Color Printing Machine

Profile Printing Line
Double Color Profile Machine

Technical Parameters

Printing Width in mm - 300, 760, 1000, 1250 mm
Printing Speed - 5-40 mtr/min
Profile/Board Thickness - 2-50 mm
Electric Power - 4.00 HP
Dimensions in mm - 2500 x 1550 x 1300 mm
  • Double Color profile printing machine, fine tuning of design, easy & simple for printing process. System runs at very high speed and gives uniform fine quality of printing. Machine can run in dual way either as single printing machine or double color printing machine.
  • The printing machine is suitable for PVC profiles doors, veneer board, plastic PVC extruded sections, Venetian blind, ceiling panel, wall panel, foam board, ACB, WPC etc.
  • The feeding speed can be adjusted coupled with the printing speed of double color printing machine.
  • The feeding speed can be adjusted couple with the coating / laminated speed.
  • Plate height can be adjusted easily and adopt quick-assemble structure for convenient maintenance.
  • The printed work piece’s face is up warded, so that the print man can be vision the printing quality, which controlled the printing quality effectively.
  • Easy for replacing the PU roller & printing roller which is just to disassembly the locking bushing for PU & printing roller and replaced, time & labour saving. This machine is designed with easy dismantle structure to make convenient clean and maintenance.
  • Safe, convenient & rapid system for ink recycling without any wastage.
  • Printing machine is available in various effective printing width and sizes. We can develop machine as per customer specification apart from below given sizes and application.
Get One Stop Complete Solution
Complete PVC Door Profile Printing Line
Profile Printing Line
Double Color Printing Machine
